Electric Distribution Switchboard Panel

Transformer Transformer Transformer Transformer Transformer Transformer Transformer

Electric Distribution Switchboard Panel

This is the best integrative solution to megawatt calss phtovoltaic power station.The system consists of 2 units of high efficient PV inverters,one unit of mid-voltage transformer(step up transformer).AC power,DC power, monitoring communications ,and other mobile devices integrated  in a mobile house, thereby enhancing the systemn security as well as relaiblility ,convinent to transport and installation ,improving system efficiency and power output as well.

  • Brand:

    WANTAI

  • Item NO.:

    XGN

  • Order(MOQ):

    1

  • Payment:

    T/T,D/P,etc.

  • Market Price:

    10000

  • Price:

    $10000/set

  • Product Origin:

    China

  • Color:

    White

  • Shipping Port:

    China port

  • Lead Time：

    45 Working days
Inquiry now
Features
1.Adjustable reactive power,power factor ranging from 0.9 leading to 0.9 lagging
2.Multi language touchable control monitoring screen.
3.One-stop solution for MW class solar photovoltaic power station.
4.Steel enclosure or environment friendly material enclosure
5.Perfect protection and friendly monitoring and control interface.
6.Environmental monitoring device shall be mounted.
7.Two inverters share a high efficency isolation transformer, which will enhance the efficiency of th system
8.Auxiliary electrical heating (optional)
9.Adaptable to <6000m(exceeding 3000m with drop in efficiency)
10.Low-voltage ride-through capability ,Adjustable reactive power,Continuously adjustable active.
Safety
1.Perfect protection:over voltage protection,short circuit protection,is landing protection,over heating protection, over-load protection,lightning protection, DC earthing protection.
2.Standard:EN61000-6-2,EN61000-6-4,EN50178,RD1663/2000.
